Daytime Running Light issue, bulb is fine?

[Veegie]

Hey guys,

I hope this is the right forum. I did a search on my issue, but I couldn't find anything specifically related to the bulb being alright.

So I realized my right halo was out today, and I had the error, "Warning - Right Daytime/Running Light".
So I picked up an H8 35w and installed it without issue.
Start up car, same error and same problem?
Is there anything I can do on my end before I bring it into the dealer tomorrow?
I was thinking of checking to see if it was even getting power, but I don't own the equipment to check that.

Is this a common issue/solution?

[Bmw135er]

I've seen a couple ground wires break off of a ground splice inside the light. Hopefully they get it taken care of for you.

[Veegie]

Thanks for the heads up! I'm going tomorrow morning and will report back with the results, in case someone comes across this thread in the future when searching.

[THE TECH]

Pick up a voltmeter. It's a valuable tool to have.

[kenwelch]

Purchase a Harbor Freight Multimeter $4.99 or go wild and buy the $20.00 version.
http://www.harborfreight.com/7-funct...ter-98025.html
There is a Harbor Freight store near you.

To Check the bulb.
1. Unplug the bulb
2. Setup the multimeter as an Ohm meter
3. Place the meter leads on each of the disconnected BULB terminals
4. Check both the "new" and old bulb. Sometimes the new part is bad.
5. You should have a small Ohms number if good. A bad bulb will display an OL on the meter, just like when the leads are not touching anything.

Another way to do this is swap the left and right side bulbs to see if the working bulb also works on the other side. This method is not as much fun as playing with the meter and sometimes leads to two broken bulbs. Don't touch the glass and don't drop the bulbs.

You can also test the voltage available at the bulb socket.
This is a 12 volt DC circuit for the DRL's, so use the 20 DCV setting on the meter. Change the meter to test DC Volts.
Turn on Day Time Running lights
Connect the voltmeter leads to each socket terminal, Brown wire terminal is ground so use the Black meter lead. The Red meter lead to the other terminal.
You should have more than 12 volts or battery voltage.

Sorry for getting carried away. I haven't taught my Automotive Electrical Systems class in weeks so I needed to vent.

[tom @ eas]

If only passenger AE is out, likely the FRM module needs to be reset.
